Timber Flood Gates

M3TFG

The Timber Flood Gate is ideal for driveways or entrances to properties where easy access is essential.

Passive Long Term Solution

Timber Flood Gates

M3TFG

The Timber Flood Gate is ideal for driveways or entrances to properties where easy access is essential.

Timber Flood Gates

The Gate is able to be closed swiftly and securely in the event of an imminent flood, while acting as a standard gate on a day to day basis.

Get a quotation

  • Passive, long-term solution
  • Designed and manufactured for use on both single and double leaf
  • Choice of wood finishes to best match surroundings
  • Easy to open and close by one person
  • Option for cast in or retro fit install
  • Tested to PAS 1188-1:2014
Timber Flood Gates Key Points
  • Passive, long-term solution
  • Designed and manufactured for use on both single and double leaf
  • Choice of wood finishes to best match surroundings
  • Easy to open and close by one person
  • Option for cast in or retro fit install
  • Tested to PAS 1188-1:2014
One Man Operation
One Man Operation

Can be easily opened and closed by one person

Low Maintenance
Low Maintenance

Virtually maintenance free for many years

Bespoke Size
Bespoke Size

Manufactured to bespoke widths and heights

Technical Information

Applications
  • Driveways.
  • Property Entrances.
  • Side Gate Entrances.
  • Vehicle Entrances.
Seals
  • The EPDM seals have excellent resistance to water absorption, ozone and UV ageing.
  • Push fit seals, making them easy to replace if necessary.
  • Easy locking shoe bolts to create the seal.
Bolts
  • J Bolts are used to lock the Gate into the floor to provide a strong fix.
  • There is an option of adding extensions to the tops of the J Bolts which allow the gate to be easily opened from either side.
Threshold
  • The Timber Flood Gate has a small threshold which is required in order to create the seal (see diagram below).
  • Concrete curb – this is mostly used when vehicles will be crossing the threshold regularly. The concrete allows for a longer lasting curb stone.
  • Wooden curb – this is used predominantly when it is pedestrian traffic over the threshold.
Timber Flood Gates
Timber Flood Gates Downloads

Timber Flood Gate Technical Document

Download File...

Timber Flood Gates: Request a Quotation

If you would like to receive a free quotation, please start a new quotation by clicking the button below.

Start New Quotation... or Call us on: 01905 676467

Your Details

Wooden Gate Details

Upload Sketch Detail :
(Including location of Rails/Oak Packers & Reveal/Face fixing / Additional work Vertical Frame sizes 140mm Width x 120mm Depth . Consider impact on reveal opening size)

Protection

Including add-ons.
Including add-ons.

Additional Works

Are there any HIGHWAYS issues or permits that may be required?
Include details of scope of works required to achieve 70mm slope? Which is on opposite side to opening

Gate Details

Type of gate required:
Opening Required:
Hinged Side:
Which Gate is required to open first (master)?
How will the gate seal at Ground Level?
How will gate posts attach?:
What is the finish of the existing wall?
Do the gates require 180 degree opening?
Are there pier caps that may impede the fitting?
